Belt Rakes T Series With Three/Four Combs
The three/four teeth belt rakes T series are designed for heavier duty jobs, suitable for low/medium power tractors. They are sturdy machines, ideal for jobs on hills and mountain, windrowing and aerating also short grass.
They have a two-bands belt with 3 or 4 teeth and can be applied frontally or behind the tractor.
- Combs movements on auto-lubricating plastic bushings
- One piece double tie-rods and pulley groups with a fixed pulley and a free one for ensuring a perfect belt alignment
- Working height adjustment done via levers on rear wheels’ uprights
- Pulleys group and transmission greasing
- Safe thanks to the CE standards protections
- Sandblasting and oven powder coating
- 2 years warranty
| SPECIFICATIONS | T 160 | T 180 | T 200 | T 220 | T 240 | T 260 |
|---|---|---|---|---|---|---|
| COMBS N° | 8×3-4 | 9×3-4 | 10×3-4 | 11×3-4 | 12×3-4 | 13×3-4 |
| REQUIRED POWER (Kw) | 15 | 16 | 19 | 22 | 26 | 30 |
| WORKING WIDTH (Cm) | 140 | 160 | 180 | 200 | 220 | 240 |
| MAX WORKING WIDTH (Cm) | 160 | 180 | 200 | 220 | 240 | 260 |
| WEIGHT (Kg) | 140 | 150 | 179 | 205 | 242 | 265 |
| BELT SUPPORTS | 0 | 0 | 0 | 0 | 1 | 1 |
